large fragment screws set 36.00.050

Large Fragment Screws Set

100 in stock

Add to quote
SKU: 436-00-050
Category:

Large Fragment Screws Set | AMAAX INTERNATIONAL – ISO 13485:2016

The Large Fragment Screws Set is a comprehensive orthopedic fixation screw system designed for large fragment fracture management and trauma surgery procedures. The set contains a range of precision-manufactured screws used with large fragment plate systems, providing reliable fixation, stability, and accurate bone compression. Manufactured from Titanium, these screws offer excellent biocompatibility, corrosion resistance, and high mechanical strength for dependable clinical performance.

Key Features

  • Complete large fragment screw assortment for orthopedic fixation
  • Designed for trauma and fracture reconstruction procedures
  • Compatible with large fragment plate systems
  • Precision-machined threads for secure bone fixation
  • Excellent compression and holding strength
  • Manufactured from Titanium
  • Biocompatible and corrosion resistant
  • Suitable for orthopedic implant applications
  • OEM and private label manufacturing available

Material

Titanium

Package Includes

1 × Large Fragment Screws Set

+------------+-----+--------------------------------------+
| Code       | Qty | Item                                 |
+------------+-----+--------------------------------------+
| 436-219-99 |  6  | Washer, Outside Ø13.0 mm,            |
|            |     | Inside Ø6.8 mm                       |
+------------+-----+--------------------------------------+
| 433-000-25 |  1  | Tray for Large Fragment Screws       |
+------------+-----+--------------------------------------+
| 436-214-14 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 14.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-16 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 16.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-18 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 18.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-20 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 20.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-22 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 22.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-24 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 24.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-26 |  7  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 26.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-28 |  7  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 28.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-30 | 14  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 30.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-32 | 14  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 32.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-34 | 14  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 34.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-36 | 14  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 36.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-38 |  7  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 38.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-40 | 14  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 40.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-42 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 42.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-44 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 44.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-45 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 45.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-46 |  6  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 46.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-48 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 48.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-50 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 50.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-52 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 52.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-55 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 55.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-56 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 56.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-60 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 60.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-62 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 62.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-64 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 64.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-68 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 68.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-214-70 |  3  | Full Threaded Cortical Screw,        |
|            |     | Ø4.5mm, 70.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-215-25 |  1  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 25.0mm Long,                 |
|            |     | Thread Length 12.0mm                 |
+------------+-----+--------------------------------------+
| 436-215-30 |  1  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 30.0mm Long,                 |
|            |     | Thread Length 15.0mm                 |
+------------+-----+--------------------------------------+
| 436-215-35 |  1  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 35.0mm Long,                 |
|            |     | Thread Length 18.0mm                 |
+------------+-----+--------------------------------------+
| 436-215-40 |  1  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 40.0mm Long,                 |
|            |     | Thread Length 20.0mm                 |
+------------+-----+--------------------------------------+
| 436-215-45 |  2  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 45.0mm Long,                 |
|            |     | Thread Length 22.0mm                 |
+------------+-----+--------------------------------------+
| 436-215-50 |  2  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 50.0mm Long,                 |
|            |     | Thread Length 24.0mm                 |
+------------+-----+--------------------------------------+
| 436-215-55 |  2  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 55.0mm Long,                 |
|            |     | Thread Length 26.0mm                 |
+------------+-----+--------------------------------------+
| 436-215-60 |  2  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 60.0mm Long,                 |
|            |     | Thread Length 28.0mm                 |
+------------+-----+--------------------------------------+
| 436-215-65 |  1  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 65.0mm Long,                 |
|            |     | Thread Length 30.0mm                 |
+------------+-----+--------------------------------------+
| 436-215-70 |  1  | Short Threaded Malleolar Screw,      |
|            |     | Ø4.5mm, 70.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-00 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 100.0mm Long,                |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-05 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 105.0mm Long,                |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-10 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 110.0mm Long,                |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-15 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 115.0mm Long,                |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-20 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 120.0mm Long,                |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-25 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 25.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-30 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 30.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-35 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 35.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-40 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 40.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-45 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 45.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-50 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 50.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-55 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 55.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-60 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 60.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-65 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 65.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-70 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 70.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-75 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 75.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-80 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 80.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-85 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 85.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-90 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 90.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-216-95 |  2  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 95.0mm Long,                 |
|            |     | Thread Length 16.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-00 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 100.0mm Long,                |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-05 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 105.0mm Long,                |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-10 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 110.0mm Long,                |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-15 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 115.0mm Long,                |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-20 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 120.0mm Long,                |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-45 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 45.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-50 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 50.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-55 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 55.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-60 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 60.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-65 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 65.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-70 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 70.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-75 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 75.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-80 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 80.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-85 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 85.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-90 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 90.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-217-95 |  3  | Short Threaded Cancellous Screw,     |
|            |     | Ø6.5mm, 95.0mm Long,                 |
|            |     | Thread Length 32.0mm                 |
+------------+-----+--------------------------------------+
| 436-218-00 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 100.0mm Long                 |
+------------+-----+--------------------------------------+
| 436-218-05 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 105.0mm Long                 |
+------------+-----+--------------------------------------+
| 436-218-10 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 110.0mm Long                 |
+------------+-----+--------------------------------------+
| 436-218-25 |  4  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 25.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-30 |  4  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 30.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-35 |  4  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 35.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-40 |  4  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 40.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-45 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 45.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-50 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 50.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-55 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 55.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-60 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 60.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-65 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 65.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-70 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 70.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-75 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 75.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-80 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 80.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-85 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 85.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-90 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 90.0mm Long                  |
+------------+-----+--------------------------------------+
| 436-218-95 |  2  | Full Threaded Cancellous Screw,      |
|            |     | Ø6.5mm, 95.0mm Long                  |
+------------+-----+--------------------------------------+

Reference Numbers

Dimeda : 36.219.99, 33.000.25, 36.214.14, 36.214.16, 36.214.18, 36.214.20, 36.214.22, 36.214.24, 36.214.26, 36.214.28, 36.214.30, 36.214.32, 36.214.34, 36.214.36, 36.214.38, 36.214.40, 36.214.42, 36.214.44, 36.214.45, 36.214.46, 36.214.48, 36.214.50, 36.214.52, 36.214.55, 36.214.56, 36.214.60, 36.214.62, 36.214.64, 36.214.68, 36.214.70, 36.215.25, 36.215.30, 36.215.35, 36.215.40, 36.215.45, 36.215.50, 36.215.55, 36.215.60, 36.215.65, 36.215.70, 36.216.00, 36.216.05, 36.216.10, 36.216.15, 36.216.20, 36.216.25, 36.216.30, 36.216.35, 36.216.40, 36.216.45, 36.216.50, 36.216.55, 36.216.60, 36.216.65, 36.216.70, 36.216.75, 36.216.80, 36.216.85, 36.216.90, 36.216.95, 36.217.00, 36.217.05, 36.217.10, 36.217.15, 36.217.20, 36.217.45, 36.217.50, 36.217.55, 36.217.60, 36.217.65, 36.217.70, 36.217.75, 36.217.80, 36.217.85, 36.217.90, 36.217.95, 36.218.00, 36.218.05, 36.218.10, 36.218.25, 36.218.30, 36.218.35, 36.218.40, 36.218.45, 36.218.50, 36.218.55, 36.218.60, 36.218.65, 36.218.70, 36.218.75, 36.218.80, 36.218.85, 36.218.90, 36.218.95

Note: Cross-reference numbers are provided for product identification and comparison purposes only.

Applications

  • Large fragment fracture fixation
  • Orthopedic trauma surgery
  • Bone reconstruction procedures
  • Plate and screw fixation
  • Femur and tibia fracture repair
  • Humerus fracture fixation
  • General orthopedic implant procedures

Sterilization

This implant set is supplied non-sterile and must be sterilized according to approved hospital sterilization procedures before surgical use.

Quality Assurance

Each Large Fragment Screws Set undergoes:

  • Titanium material verification
  • Precision machining inspection
  • Thread accuracy testing
  • Dimensional inspection
  • Surface finish evaluation
  • Corrosion resistance testing
  • Final quality inspection before shipment

Warranty

AMAAX INTERNATIONAL provides a 3-Year Warranty against manufacturing defects under normal storage and handling conditions.

Packaging

  • Medical-grade protective packaging
  • Secure implant storage box
  • Batch traceability labeling
  • OEM and private label packaging available

large fragment screws set, orthopedic bone screws, titanium fixation screws, trauma surgery implants, fracture fixation screws, orthopedic implant system, bone reconstruction screws, titanium orthopedic implants, reusable surgical instruments, OEM orthopedic implants, AMAAX INTERNATIONAL

Reviews

There are no reviews yet.

Be the first to review “Large Fragment Screws Set”

Your email address will not be published. Required fields are marked *


Related Products
