Short Threaded Malleolar Screw, Dia. 4.5mm

Short Threaded Malleolar Screw 4.5mm | AMAAX INTERNATIONAL – ISO 13485:2016

The Short Threaded Malleolar Screw 4.5mm is a precision orthopedic fixation implant designed for secure stabilization of malleolar fractures, ankle reconstruction, and small bone fixation procedures. Manufactured from German Stainless Steel, this screw provides excellent mechanical strength, corrosion resistance, and reliable fixation performance. The optimized short thread design allows controlled compression and strong bone engagement while maintaining accurate anatomical alignment.

---

Key Features

• Short threaded malleolar screw design
• Screw diameter: 4.5 mm
• Available with multiple thread length options
• Precision-machined thread profile for secure fixation
• Provides controlled compression and stability
• Designed for ankle and small bone fixation procedures
• High mechanical strength and fatigue resistance
• Corrosion-resistant stainless steel construction
• Suitable for orthopedic trauma applications
• OEM and private label manufacturing available

---

Material

German Stainless Steel

---

General Size

Screw Diameter: 4.5 mm
Lengths: 20.0 mm, 25.0 mm, 30.0 mm, 35.0 mm, 40.0 mm, 45.0 mm, 50.0 mm, 55.0 mm, 60.0 mm, 65.0 mm, 70.0 mm, 75.0 mm, 80.0 mm
Thread Lengths: 9.0 mm, 12.0 mm, 15.0 mm, 18.0 mm, 20.0 mm, 22.0 mm, 24.0 mm, 26.0 mm, 28.0 mm, 30.0 mm, 32.0 mm, 34.0 mm, 36.0 mm

Package Includes

1 × Short Threaded Malleolar Screw 4.5mm

---

Reference Numbers

Amaax International : 436-215-20, 436-215-25, 436-215-30, 436-215-35, 436-215-40, 436-215-45, 436-215-50, 436-215-55, 436-215-60, 436-215-65, 436-215-70, 436-215-75, 436-215-80

Dimeda : 36.215.20, 36.215.25, 36.215.30, 36.215.35, 36.215.40, 36.215.45, 36.215.50, 36.215.55, 36.215.60, 36.215.65, 36.215.70, 36.215.75, 36.215.80

Other : 25-115-20, 25-115-25, 25-115-30, 25-115-35, 25-115-40, 25-115-45, 25-115-50, 25-115-55, 25-115-60, 25-115-65, 25-115-70, 25-115-80, 75.15.25, 75.15.30, 75.15.35, 75.15.40, 75.15.45, 75.15.50, 75.15.55, 75.15.60, 75.15.65, 75.15.70, LA225, LA230, LA235, LA240, LA245, LA250, LA255, LA260, LA265, LA270

Note: Cross-reference numbers are provided for product identification and comparison purposes only.

---

Applications

• Malleolar fracture fixation
• Ankle fracture stabilization
• Medial and lateral malleolus reconstruction
• Small bone trauma fixation
• Orthopedic reconstructive procedures
• Foot and ankle surgery

---

Sterilization

This implant is supplied non-sterile and must be sterilized according to approved hospital sterilization procedures before surgical use.

---

Quality Assurance

Each Short Threaded Malleolar Screw 4.5mm undergoes strict quality control including:

• Raw material verification
• Thread accuracy inspection
• Dimensional measurement
• Surface finish evaluation
• Mechanical strength testing
• Final product inspection

---

Warranty

AMAAX INTERNATIONAL provides a 3-Year Warranty against manufacturing defects under normal storage and handling conditions.

---

Packaging

• Individually packed
• Medical-grade protective packaging
• Batch traceability labeling
• OEM and private label packaging available

---
