Quadrangular Positioning Plate

Quadrangular Positioning Plate 110°/90°/90°/70° | AMAAX INTERNATIONAL – ISO 13485:2016

The Quadrangular Positioning Plate 110°/90°/90°/70° is a precision-engineered orthopedic surgical instrument designed for accurate positioning and alignment during hip and fracture fixation procedures. Manufactured from AISI 420 German Stainless Steel, it provides excellent mechanical strength, corrosion resistance, durability, and reliable surgical performance. The quadrangular design with multiple angled configurations allows precise guidance and controlled placement during orthopedic reconstruction procedures. A pediatric version is also available for children’s applications.

---

Key Features

• Precision-engineered quadrangular positioning plate
• Available in 110° / 90° / 90° / 70° angled configurations
• Pediatric version available for children
• Designed for accurate implant positioning and alignment
• Suitable for orthopedic trauma and reconstruction procedures
• Manufactured from AISI 420 German Stainless Steel
• High mechanical strength and long service life
• Precision-machined angles for accurate surgical guidance
• Corrosion-resistant surface finish
• Reusable orthopedic surgical instrument
• OEM and private label manufacturing available

---

Material

AISI 420 German Stainless Steel

---

Package Includes

1 × Quadrangular Positioning Plate

---

Reference Numbers

Amaax International : 434-333-10, 434-333-16

Dimeda : 34.333.10, 34.333.16

Zepf : 34-2313-10, 34-2313-16

Other : 09-0310, 17.02.022, 25-233-10, 304-03313-10, 333.10, 38319-01, 425037986108, 8-7618, IP8416-00, 09-0328, 25-233-16, 304-03313-16, 333.16, 425037986109

Note: Cross-reference numbers are provided for product identification and comparison purposes only.

---

Applications

• Hip fracture fixation procedures
• Orthopedic implant positioning
• Femoral reconstruction surgery
• Trauma surgery applications
• Pediatric orthopedic procedures
• Plate and screw fixation techniques
• Bone alignment and stabilization

---

Sterilization

This instrument is supplied non-sterile and must be sterilized according to approved hospital sterilization procedures before surgical use.

---

Quality Assurance

Each Quadrangular Positioning Plate undergoes strict quality control including:

• Raw material verification
• Precision machining inspection
• Angle accuracy testing
• Dimensional verification
• Surface finish evaluation
• Corrosion resistance testing
• Final quality inspection before shipment

---

Warranty

AMAAX INTERNATIONAL provides a 3-Year Warranty against manufacturing defects under normal storage and handling conditions.

---

Packaging

• Individually packed
• Medical-grade protective packaging
• Batch traceability labeling
• OEM and private label packaging available

---
